The Chord Progression Tool (available in FL Studio's All Plugins Edition) is a visual interface for building harmonic progressions. It reduces the gap between "I want to try some chord ideas" and "here are notes in the Piano Roll ready to arrange." This guide covers how to use it, what makes it useful, and where it fits in a broader composition workflow.
Finding the Chord Progression Tool
The Chord Progression Tool lives in the Channel Rack — add it as you would any other instrument (right-click, search "Chord Progression"). Once loaded, it opens as a plugin with a grid of chord blocks.
Selecting a Key and Scale
At the top of the interface, set your root key and scale (major, minor, Dorian, Mixolydian, and others). This establishes the harmonic context. All chords in the grid will be generated from this scale, so every combination you try is musically coherent within your chosen key.
For most beginner and intermediate producers, minor or major scales are the most familiar starting points. Dorian is worth exploring for a slightly less resolved, more modal sound often found in ambient, lo-fi, and soul music.
Building a Progression
The chord blocks in the grid represent the chords available in your scale (scale degrees I through VII). Click a block to trigger that chord through any connected instrument (or through the Chord Progression Tool's own built-in audio output).
To build a progression, click blocks in sequence. The tool records your clicks as a pattern. Experiment with different chord combinations and listen to which sequences create the emotional quality you are after.
Common effective progressions in minor:
• i – VI – III – VII: Melancholic, cinematic
• i – iv – VII – III: Dark, flowing
• VI – VII – i: Simple, intense resolution
The Bassline Generator
Added in FL Studio 2025, the Bassline Generator creates a complementary bassline based on your selected chord progression. Click Generate Bassline after building your progression and FL Studio outputs a bass pattern in the Piano Roll that follows the harmonic structure.
The generated bassline is a starting point, not a finished line. It typically plays root notes with some rhythmic variation — useful as a foundation to modify rather than a finished composition.
Exporting to the Piano Roll
Once you have a progression you want to use:
1. Click Send to Piano Roll. The chord progression is written as Piano Roll notes, one chord per bar (or at whatever duration you configured).
2. You can now edit the chords in the Piano Roll — adjust voicings, change rhythm, add extensions, or modify individual notes.
3. Route the Chord Progression Tool channel to a Mixer track and connect an instrument (or use the tool's internal sound).
The export is clean and editable. Everything the Chord Progression Tool generates, you can modify in the Piano Roll.
Limitations and How to Work Around Them
The Chord Progression Tool is excellent for exploration and starting points, but it has limitations:
• Chord voicings are fixed: The tool does not let you customise which inversion or voicing each chord uses. For specific voicings, edit the exported Piano Roll notes manually.
• Rhythm is basic: The tool places chords at regular intervals. Complex rhythmic chord patterns need to be programmed in the Piano Roll.
• Available in All Plugins Edition only: If you are on Producer, Fruity, or the free trial, use the Chord Stamp Tool in the Piano Roll instead (it is available in all editions).
